Derricks
Amos Oilfield Fabrication LLC specializes in mobile fabrication, welding, and API inspections for oilfield, construction, and heavy equipment. From derricks to trucks, we deliver certified, on-site solutions that save you time and reduce downtime.
Manufacturer
All Hornet Derricks are built to API 4F standards
The derricks range in size from 71 to 112 feet and hook load capacities from 150,000 to 300,000 pounds. Hornet has the derrick for any application. All Hornet Derricks are independently inspected by certified third party inspectors to ensure the highest quality. A proprietary construction method make the Hornet Derrick one of the best in the field.
- Rectangular tubing design
- McKissick sheaves
- Automatically deployed tubing board and rod basket
- Completely welded in house
- Hydraulically raised and scoped
Lorem ipsum
0
+
HEIGHTS
71′
96′
104′
104′
108′
108′
112′
112′
HOOK LOAD CAPACITIES
150,000 lbs
225,000 lbs
250,000 lbs
300,000 lbs
250,000 lbs
300,000 lbs
250,000 lbs
300,000 lbs
MAX # OF LINES
4
6
6
8
6
8
6
8
